ELB-REV4 iSCADA

High performance data acquisition

The SCADA is a Linux-based embedded board providing real-time performance in a small form factor. Anchored by TI’s ARM cortex-A8 1-Ghz processor, SCADA is integrated with the following on board: RS232/serial interface (2), RS485 interface (2), CAN interface, LTE modem, Wifi, Ethernet, eMMC, SD card, USB (2), 512MB SRAM, 1024K eprom, I2C, SPI, 8 LED’s, 4 switches and 20 GPIO’s.

A rich set of API is provided for quick project startup. This product is designed to serve clients in the fields of automotive, telecom, medical, remote automation, and industrial control.

We specialise in TI Sitara, sitara processor, Embedded single board computers, SCADA industrial hardware, Quectel LTE modem, embedded projects, industrial mini pc, sitara ARM cortex processor, Embedded linux single board computer, SCADA device, evaluation board, RS485 , RS232, CAN, linux board, industrial hardware with RS232, industrial computer, gnu arm embedded toolchain, FreeRTOS, fanless CPU, embedded project SCADA, embedded data acquisition, embedded beaglebone black, ARM processor, ARM CPU, arm gcc compiler, arm gcc, ARM cortex A8 CAN, ARM chipset, A8 processor, cubox i, IMX6, IMX8, and LTE Raspberry pi.

Key Features:

CPU:

  • Texas Instruments TI sitara AM335X.
  • High Performance with 1GHz Cortex-A8.
  • PowerVR SGX530 Graphics core.
  • 512MB DDR3 RAM.
  • 4GB eMMC memory and SD card slot.

Networking:

  • Wireless connectivity: Wi-Fi: 802.11 b/g/n.
  • 10/100Mbps Ethernet.
  • LTE Modem for various regions.
  • LoRa supported Bands 868 , 915 , 433 MHz

Peripheral interfaces:

  • 2 × 12-bit SAR ADC
  • 1 × SPI
  • 1 × I²C interfaces
  • 1 × CAN
  • 25 × GPIO pins
  • 2 × Timer/Counter
  • 1 × RESET, WakeUp

Serial Interface:

  • 2 × RS232.
  • 2 × RS485.

Cryptographic hardware acceleration:

  • AES, SHA-2, RSA, elliptic curve cryptography (ECC), random number generator (RNG)

Power management:

  • Internal low-dropout regulator
  • Individual power domain for RTC
  • 5uA deep sleep current
  • Wake up from GPIO interrupt, timer.

Display Resolution:

  • Resolution 1400 × 1050 × 24 bpp
  • LCD interface Parallel RGB 24 bit.
  • 4/5 wire resistive touch panel

USB:

  • 1 × USB Host
  • 2 × USB OTG

Software Update:

  • Over The Air software can be update via wifi, LTE modem, Ethernet.

Dimensions (W × L × H):

  • 110 mm x 100 mm x 39 mm

OS support:

  • Linux Arago

EFB-REV1 IoT

Overview:

The EFB-REV1 boots up in less than 200ms. runs on FreeRTOS Provides a powerful and flexible selection across the full spectrum of applications.Built in LoRa module Arduino  suits it perfect for application like Smart metering, Smart lighting, Smart home, Smart Energy, Automation and Industrial solution. Documentation hardware/software customisation completely supported by our team. Power supply and USB cable provide along with the box for debugging.

A rich set of API is provided for quick project startup. This product is designed to serve clients in the fields of automotive, telecom, medical, remote automation, and industrial control.

Key Features:

CPU:

  • Xtensa dual-core 32-bit LX6 microprocessor, operating at 240 MHz
  • Performing at up to 600 DMIPS.
  • 520 KiB SRAM.
  • 4MB Flash memory

Networking:

  • Wireless connectivity: Wi-Fi: 802.11 b/g/n.
  • font-size: 1rem;”>Bluetooth v4.2 BR/EDR and BLE
  • LoRa supported Bands 868 , 915 , 433 MHz

Peripheral interfaces:

  • 12-bit SAR ADC up to 12 channels
  • 2 × 8-bit DACs
  • 1 × I²C interfaces
  • 2 × UART
  • 20 × GPIO pins

Performance:

  • Data transfer rates Upto 300kb/s using LoRa communication.

Cryptographic hardware acceleration:

  • AES, SHA-2, RSA, elliptic curve cryptography (ECC), random number generator (RNG)

Power management:

  • Internal low-dropout regulator
  • Individual power domain for RTC
  • 5uA deep sleep current
  • Wake up from GPIO interrupt, timer, ADC measurements

Sensor connectivity:

  • Maximum 6 Analog sensors can be connected with total load of 880mA.

Software Update:

  • Over The Air software can be update via wifi or Bluetooth.

Dimensions (W × L × H):

  • 75 mm x 75 mm x 32 mm

OS support:

  • FreeRTOS

ELB-REV4 iSCADA webPanel SOFTWARE

  • SCADA powers with 5V 2A DC power supply.
  • A webPanel Desktop application that monitors the iSCADA device
  • For Modem to work make sure SIM PIN is disabled.
  • SIM Card can only be ejected by pressing the SIM eject button.
  • RS485 and RS232 are industrial purpose ports.
  • Mini USB port is only used to collect log messages
